Sirui PH-20 Gimbal Head

The Sirui PH-20 Gimbal Head is a great solution to the problem of shooting moving subjects with a long telephoto lens. Ball heads and 3-way heads can be cumbersome in fast-moving situations, but the gimbal head makes your camera and heavy lens seemingly weightless, and you can smoothly and precisely track fast-moving subjects.

Cross-patterned, multi-layer carbon fiber in the arm and forged aircraft aluminum alloy in the L-bracket make the PH-20 very strong--it can hold up to 44 lb, but it weighs only 2.4 lb. Carbon fiber also reduces vibrations and provides better tolerance for temperature changes.

With the camera and lens perfectly balanced on the gimbal head, there’s no need to lock any controls. You can quickly and easily move your camera in any direction with a very light amount of force. In fact, a correctly aligned system can be controlled with one finger.

Exceptionally strong carbon fiber and aluminum alloy gimbal head
Supports up to 40 lb, but only weighs 2.4 lb
Reduced vibrations and better tolerance for temperature changes due to carbon fiber construction
Arca-compatible quick release system, calibrated quick release platform, and included quick release plate
Horizontal 360° range, and tilt of +150° to -60°
Ideal for using long telephoto lenses to photography moving subjects
Sirui PH-20 Specs
General
Head Type Gimbal Head
Base Mount 3/8"-16 Thread
Camera Mounting Screw 1/4"-20 Male
Load Capacity 44 lb / 20 kg
Independent Pan Lock Yes
Physical
Dimensions H: 9.1 x W: 9.1 x L: 4.7" / H: 23.0 x W: 23.0 x L: 12.0 cm
Weight 2.4 lb / 1.1 kg
Packaging Info
Package Weight 5.0 lb
Box Dimensions (LxWxH) 12.6 x 12.1 x 4.0"in the box
